Product Description
|
Certification |
TUV |
|
Certificate |
No. B 101149 0002 Rev.00 |
|
Standard |
EN62852:2015 |
|
Rated Voltage |
1500VDC |
|
Test Voltage |
6000V(50Hz 1min) |
|
Rated Current |
30A |
|
Protection Class |
Class A |
|
Protection Degree |
IP67 |
|
Flame Class |
UL94-V0 |
|
Overvoltage Category |
III |
|
Pollution Degree |
2 |
|
Temperature Range |
-40℃~+85℃ |
|
Upper Limiting Temperature |
100℃ |
|
Contact resistance |
≤0.5mΩ |
|
Insulation resistance |
>500MΩ |
|
Insert force |
≤50N |
|
Pullout force |
≥50N |
|
Connecting Cable |
1×4mm 2 |
|
Waterproofing structure |
O-ring Seal |
|
|
|
Advantages
1. Compatible for PV solar connector.
2. Easy and quick for assembling.
3. High quality Material
4. High carrying capacity
-
1500V DC rated voltage
-
30A rated current
-
IP67 waterproof level perform well in PV system installation programs
5. Optional pins
6. Quality reliable: TUV,ISO,CE and IEC certificates and 2 year warranty and 25-year working time.
7. Safety lock lock design with special PV solar connector spanner tool
