182mm Mono Solar Panel 400w solar power
SF390~415M10
390W-415W
182MM 108 string single crystal photovoltaic modules.
Specification
| Model | SF390M10 | SF395M10 | SF400M10 | SF405M10 | SF410M10 | SKT415M10 | ||||||
| STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | |
| Max power- Pm ax(W ) | 390 | 294 | 395 | 298 | 400 | 302 | 405 | 306 | 410 | 310 | 310 | 314 |
| Open voltage- Voc(V) | 36.85 | 34.62 | 36.98 | 34.75 | 37.07 | 34.88 | 37.23 | 35.12 | 37.32 | 35.23 | 35.23 | 35.37 |
| Short current- Isc(A) | 13.61 | 10.89 | 13.7 | 10.96 | 13.79 | 11.03 | 13.87 | 11.1 | 13.95 | 11.16 | 11.16 | 11.22 |
| Work voltage-Vm p(V) | 30.64 | 28.87 | 30.84 | 29.08 | 31.01 | 29.26 | 31.21 | 29.47 | 31.45 | 29.72 | 29.72 | 29.89 |
| Work current- Im p(A) | 12.73 | 10.18 | 12.81 | 10.25 | 12.9 | 10.32 | 12.98 | 10.38 | 13.04 | 10.43 | 10.43 | 10.5 |
| Efficiency-ηm (% ) | 20 | / | 20.2 | / | 20.5 | / | 20.8 | / | 21 | / | / | / |
| Power tolerance(W ) | (0,+4.99W) | |||||||||||
| Maximum system voltage(V) | 1500Vdc (IEC / UL) | |||||||||||
| Maximum rated fusing current(A) | 25A | |||||||||||
STC: Light intensity 1000W/m, component temperature 25 ℃, atmospheric quality 1.5
NOCT: Light intensity 800W/m, ambient temperature 20 ℃, atmospheric quality 1.5, wind speed 1m/s
| Size | 1722x1134x30m m |
| Weight | 20.5kg |
| Solar cell | Monocrystalline 182mm (2x54pcs) |
| Glass | Coating film,3.2mm tempering glass,low iron |
|
Frame |
Anodized aluminum alloy |
|
Junction Box |
IP68 |
| Output | 4.0mm²,Customizable length |
| Connector | MC4 |
| Mechanical load | Front maximum 5400Pa,Back maximum 2400Pa |
| Maximum power temperature coefficient | -0.35%/℃ |
| Open circuit voltage temperature coefficient | -0.275%/℃ |
| Short circuit current temperature coefficient | +0.045%/℃ |
| working temperature | -40～+85℃ |
| Rated working battery cell temperature | 45±2℃ |
Qinhuangdao Sufu Electronic Co., Ltd is a modern solar module, solar system solutions and service supplier. Our solar products range from solar modules to solar power systems, solar street lights, solar multi-functional chargers, solar folding panels, portable power generators, solar pump and photovoltaic power stations, building attached photovoltaic(BAPV), building integrated photovoltaic(BIPV) design and construction.
Sufu Electronics is trying to make solar power, which is an inexhaustible, ubiquitous, green renewable energy, into thousands of homes and become eternal power for sustainable.
