Advantages
Cost-friendly: Solar energy is free solution, so you won't have a hefty electricity bill, and there's minimal maintenance required.
Eco-friendly: Solar energy systems with solar panel with battery and inverter rely on solar power, so you're doing your part for the environment.
Great Options for Rural Areas
Great for Emergencies: Even if you're not living in a rural area, you can take comfort knowing that you've got backup power in case of an emergency.
Easy to Maintain: Off-grid solar systems with solar panel with battery and inverter are sturdy and don't require much maintenance, all you need to do is occasionally clean the body and change the battery bank.
Specification
| Configuration of Home Use 3KVA Off Grid Solar Energy Systems | |||
|
Item |
Model |
Description |
Quantity |
|
1 |
Mono Solar Panel SW480M-144 |
Half Cut MBB Solar Panel |
6pcs |
|
2 |
Off Grid Inverter built-in 60A MPPT Controller |
Load Power:3KVA DC Voltage:24V/48V |
1pc |
|
3 |
Gel or Lithium Battery (Optional) |
12V/24V/48V 6KWH |
1set |
|
4 |
PV Cable |
200m PV 4mm² |
200m |
|
5 |
PV Combiner Box |
With Switches, Breaker,SPD |
1pc |
|
6 |
MC4 Connector |
Rate Current:30A |
10pairs |
|
7 |
Mounting System (including all parts) |
Whole set for 6pcs solar panel |
1set |
| Configuration of Home Use 5KW Off Grid Solar Energy Systems | |||
|
Item |
Model |
Description |
Quantity |
|
1 |
Mono Solar Panel SF480M-144 |
Half Cut MBB Solar Panel |
12pcs |
|
2 |
Off Grid Inverter built-in 80A MPPT Controller |
Load Power:5KW DC Voltage:48V |
1pc |
|
3 |
Gel or Lithium Battery (Optional) |
12V/24V/48V 12KWH |
1set |
|
4 |
PV Cable |
200m PV 4mm² |
200m |
|
5 |
PV Combiner Box |
With Switches, Breaker,SPD |
1pc |
|
6 |
MC4 Connector |
Rate Current:30A |
10pairs |
|
7 |
Mounting System (including all parts) |
Whole set for 12pcs solar panel |
1set |
| Configuration of Home Use 10KW Off Grid Solar Energy Systems | |||
|
Item |
Model |
Description |
Quantity |
|
1 |
Mono Solar Panel SF480M-144 (Optional) |
Half Cut MBB Solar Panel |
24pcs |
|
2 |
Off Grid Inverter built-in 80A MPPT Controller |
Load Power:5KW DC Voltage:48V |
2pcs |
|
3 |
Gel or Lithium Battery (Optional) |
12V/24V/48V 24KWH |
1set |
|
4 |
PV Cable |
200m PV 4mm² |
200m |
|
5 |
PV Combiner Box |
With Switches, Breaker, SPD |
2pcs |
|
6 |
MC4 Connector |
Rate Current:30A |
10pairs |
|
7 |
Mounting System (including all parts) |
Whole set for 24pcs solar panel |
1set |
| Configuration of Home Use 15KW Off Grid Solar Energy Systems | |||
|
Item |
Model |
Description |
Quantity |
|
1 |
Mono Solar Panel SW480M-144 (Optional) |
Half Cut MBB Solar Panel |
24pcs |
|
2 |
Off Grid Inverter built-in 80A MPPT Controller |
Load Power:5KW DC Voltage:48V |
3pcs |
|
3 |
Gel or Lithium Battery (Optional) |
12V/24V/48V 36KWH |
1set |
|
4 |
PV Cable |
200m PV 4mm² |
200m |
|
5 |
PV Combiner Box |
With Switches, Breaker,SPD |
3pcs |
|
6 |
MC4 Connector |
Rate Current:30A |
10pairs |
|
7 |
Mounting System (including all parts) |
Whole set for 36pcs solar panel |
1set |
Application
Solar panel with battery and inverter off-grid system is suitable for families, island, none or short of electricity area, Satellite Ground Stations, weather stations,forest fire stations, etc.
Features
1. Long-term, sustainable power;
2. Reliable, maintenance-free performance;
3. Easy and quick installation;
4. Simple control interface;
