Product Description
|
Certification |
TUV |
|
Certificate No. |
R50183265 |
|
Standard |
EN50521:2008 |
|
Rated Voltage |
1000VDC |
|
Test Voltage |
6000V(50Hz 1min) |
|
Rated Current |
30A |
|
Protection Class |
Class Ⅱ |
|
Protection Degree |
IP65 |
|
Flame Class |
UL94-V0 |
|
Overvoltage Category |
III |
|
Pollution Degree |
2 |
|
Temperature Range |
-40℃~+85℃ |
|
Upper Limiting Temperature |
105℃ |
|
Contact resistance |
≤0.5mΩ |
|
Insulation resistance |
>500MΩ |
|
Insert force |
≤50N |
|
Pullout force |
≥50N |
|
Connecting Cable |
1×4mm2 |
|
Waterproofing structure |
O-ring Seal |
|
|
|
Function
- Suitable 2.5mm2, 4mm2 and 6mm2 PV Connector
- Simple on-site processing
- Mating safety provided by keyed housings
- Multiple plugging and unplugging cycles
Application
- This solar panel connector with 4mm wire is widely used in:
- Stripping line
- Crimp
- Insert the into Male/Female
- Tighten Male/Female
About US
- We are a reliable manufacturer of Solar panel connector with 4mm wire.
- We have full of experiences for project design.
- Free bom list and drawing design please contact me.
If you need Solar panel connector with 4mm wire or solar panel or anyother products about solar, just contact us, you can get professional advice.
