Product Description
Easy installation Safety and reliability Flexibility and adjustable 10 years manufacturing experience. Exporting products all over the world. High quality, you can use our products in confidence. Although our price is not expensive, We will not cut corners. We use the best materials.
Parameters
|
Certification |
TUV |
|
Certificate No. |
R50183265 |
|
Standard |
EN50521:2008 |
|
Rated Voltage |
1000VDC |
|
Test Voltage |
6000V(50Hz 1min) |
|
Rated Current |
30A |
|
Protection Class |
Class Ⅱ |
|
Protection Degree |
IP65 |
|
Flame Class |
UL94-V0 |
|
Overvoltage Category |
III |
|
Pollution Degree |
2 |
|
Temperature Range |
-40℃~+85℃ |
|
Upper Limiting Temperature |
105℃ |
|
Contact resistance |
≤0.5mΩ |
|
Insulation resistance |
>500MΩ |
|
Insert force |
≤50N |
|
Pullout force |
≥50N |
|
Connecting Cable |
1×4mm2 |
|
Waterproofing structure |
O-ring Seal |
Benifits
- Easy installation
- Safety and reliability
- Flexibility and adjustable
Company Advantages
- 10 years manufacturing experience. Exporting products all over the world.
- High quality, you can use our products in confidence.
- Although our price is not expensive, We will not cut corners. We use the best materials.
